Export 4W 94” high speed chain stitch multi needle quilting machine to Mexico
Specification:
| Overall (L*W*H) | 5400*1650*2050 |
| Over all weight | 4800kg |
| Qquilting width | 2450 |
| Row spacing | 50.8,76.2,127(5'') 76.2,76.2,152.4(6'') |
| Needle distance | 25.4 |
| X stroke | 304.8 |
| quilting thickness | ≤80 |
| Stitch | 3-8mm |
| Output | 60-300(m/hour) |
| Needle type | 24/180 23/160 22/140 21/130 |
| Spindle speed | 500-1200(rpm) |
| Rated voltage | 380v/220v 50HZ/60HZ |
| Power | 7KW |
1) Much higher quilting quality ,much higher quilting speed,much higher quilting thickness. |
| 2) By using cone-type instead of shuttle-type in bottom yarn.It is capable of working continuously. |
| 3) Maximum working speed is to be increased 1200RPM & it elevates the productivity. |
4) Various kind of thick products which are made of sponges like as the mattress for bad are also available. |
5) By 14’color monitor.Shows information on current job graphically(eg. Stitches number, coordinate value,etc) |
