1.This machine only needs a Small footprint, one worker can operate and save cost.
2. The size of spring bed mesh, steel wire diameter,spring diameter and height can be changed within a certain range.
3.It Can realize upper and lower string spring, and when the string spring forward is blocked, it can automatically protect the stop, and after the coil spring is in place, the cutting receiver can be moved and a row of spring or forward row spring is introduced.
4. The automatic cutting and bending of the string spring can be realized.
5. The bed network automatically moves forward, and the coil spring can stop automatically when the spring is blocked.
6. The number of spring rows can be set by computer, and the whole spring bed network can be automatically launched after completion.
7. There is no need for air compressor to operate. The automatic lubrication system extends the service life of the machine, and rarely needs to be maintained and replaced.
8. Thisproduct can achieve a machine work multiple models and specifications of the bed net, a machine can be able to achieve 1 meter.
1.2 meters, 1.5 meters, 1.8 meters, 2 meters of bed net, once formed. without the mold.
9.It Can provide different specifications of fixture accessories according to customer processing requirements.
Technical Data | |
Productivity | 60-80/hour |
Net maximum width | 2m |
String Spring Wire Diameter | Φ1.3-1.6mm |
Spring Wire Diameter | Φ1.9-2.4mm |
Spring Caliber | 55mm:Φ53-55mm |
Spring Height | 60-200mm |
Power Suply | 3Phase,380V,50Hz |
Total Power | 4.5kw |
Dimensions | 3100×960x1900mm |
Weight | 1050kg |
